The KORRODEST NG (New Generation)

The modernized classic. Proven worldwide for decades, adapted to the requirements of the 21st century.

Intelligent low-temperature vacuum evaporation with consistent system separation. This ensures no direct contact between the medium and the compressor. Available in a variety of high-quality materials.

Chloride-containing media do NOT limit the application possibilities.

Excellent efficiency even at high concentrations through state-of-the-art heat pump technology and intelligent process control.

Also available with optional heat recovery for coupling to e.g. KORRODEST ZLD evaporator systems.

Individually configurable switchgear which, if desired, also monitors peripheral system components (buffer tanks, lifting pumps, etc.). Process visualization via generously sized touch panels, also remote monitoring on request.

PLC system Siemens SIMATIC, easy spare parts management thus ensured worldwide.



Korrodest NG vacuum evaporators - K are characterized by the following features:



  • Gentle product treatment through low-temperature technology
  • Consistent system separation of medium and energy generation. "Wear and tear due to use and application" is thus almost eliminated.
  • Integrated heat pump Low boiling temperature (+35°C), resulting in highest distillate quality and minimal fouling risk
  • Low purity requirements for the product due to reduced operating temperature Suitable for acidic and/or chloride-containing media.
  • The material selection is done by our application technology.
  • Sophisticated and further developed design over decades.
  • Wide range of delivery options which can be configured according to the application requirements.






KNG_BILD
blockHeaderEditIcon

KNG_Text_2
blockHeaderEditIcon
KNG_Bild_2
blockHeaderEditIcon
KNG_Text_3
blockHeaderEditIcon
KNG_Bild_3
blockHeaderEditIcon
KNG Bild
blockHeaderEditIcon

KORRODEST K new generation



500

750

1000

1500

2000

2500

3500

5000

7000

10000

12000

15000

18000

24000


Destillatleistung

Evaporated water

l/h

21

31

42

63

83

104

146

208

292

417

500

625

750

1000

Installierte Leistung

Installed power

KW

8

11

14

18

24

30

40

50

70

90

100

125

150

210

Max. Antriebsleistung

Max. absorbed power

KW/h

2,29

3,44

4,17

6,25

8,33

10,42

13,85

18,75

29,17

37,50

45,00

56,25

67,50

100

Energiebedarf bis herab

Consumption

KW/l

0,11

0,11

0,1

0,1

0,1

0,1

0,095

0,09

0,09

0,08

0,08

0,08

0,075

0,075

Länge / length

mm

1700

2000

2000

2500

2500

2800

3500

3500

3750

3750

4000

4500

5000

5000

Breite / width

mm

900

900

1000

1100

1100

1300

1500

1500

1500

1700

1700

1900

2000

2000

Höhe / heigth

mm

2200

2500

2500

2800

2800

3000

3000

3000

3500

3500

4500

4750

4800

5200

Gewicht / weight

kg

550

750

800

950

1200

1500

1850

2650

3150

4000

4250

5350

6500

7200

Alle Angaben ohne Gewähr. Irrtümer, Änderungen und Druckfehler vorbehalten.
